SetaCheck Ethanol – SA7500-0
SetaCheck Ethanol is a handheld instrument designed to provide fast, accurate and repeatable on-site measurement of ethanol content in gasoline.
Using unique electrical property measurement technology, the analyser has a measurement range of 0% to 100% ethanol. Less than 5 ml of sample is required and a test is completed in less than 1 minute with results displayed on a bright backlit screen.
SetaCheck’s test procedure is simple, requiring no special technical skills or laboratory conditions, making it ideal for batch checking fuels at terminals to monitoring standby fuel supplies.
Methods
ASTM D8274, IP 639
Features
- 0% to 100% measurement range
- Portable, handheld
- Less than 5 mL of sample required
- Simple to use
- Unique electrical property measurement technology
- Automatic temperature measurement and correction
- Rapid test time
- Bright, backlit screen
- User calibration via PC software
Details
Supplied with: USB charging cable, 3 x tube assembly, 2 x sample beakers, disposable gloves, USB with manual and a quick start guide.
Specifications
| Range | 0% to 100% |
| Operating temperature | 5 – 40 °C |
| Test duration | Less than 1 minute |
| Measuring units | % by volume |
| Sample volume | approx. 5 ml |
| Number of tests | In excess of 200 tests saved to device |
| Charging | Micro USB |
| Power | Rechargeable Lithium Ion battery (meets IATA DGR (UN3481-IP1967)) |
| Size (HxWxD) | 36 x 150 x 200 mm |
| Weight | 1 kg |
